Accurate Control of Product Weight
The checkweigher is used to reject products with inappropriate weight.
Wide Range of Use
... weighers can be used to check the weight of bags, boxes, cans, jars, etc. The weighers are suitable for food and non-food applications.
Optional Accessories
We supply checkweighers including optional accessories.
Full Stainless Steel Design
... AISI 304 steel is used for the production of weighers.
Most Advanced Weighing Modules
... enable high performance and weighing accuracy.
Stable Frame Structure
... ensures compliance with high weighing accuracy.
Digital Filter
... adjustable according to performance, size and weight of goods.
Easy Operation and Maintenance, Individual Settings
... clear control system on the touch screen ... programs in memory for individual products ... simple frame, removable conveyors without the need for tools.
PC Outputs
... for exporting production results to MS Excel.
USB Port
... with the possibility of exporting files to MS Excel.
Technical Parameters
| Weight Type | ACW-16.28 | ACW-23.35 | ACW-23.45 | ACW-30.50 | ACW-40.65 |
| Weighing Range | 10 - 600 g | 20 - 2000 g | 20 - 2000 g | 20 - 5000 g | 20 - 10000 g |
| Scale Resolution | 0,05 g | 0,1 g | 0,1 g | 0,2 g | 1,0 g |
| Expected Accuracy 1) | ±0,1 g | ±0,2 g | ±0,2 g | ±0,5 g | ±1,0 g |
| Output up to | 200 pieces/min. | 180 pieces/min. | 120 pieces/min. | 100 pieces/min. | 80 pieces/min. |
| Belt Speed 2) | 70 m/min. | 70 m/min. | 70 m/min. | 70 m/min. | 70 m/min. |
| Product Size (W x L) | 150 x 200 mm | 220 x 250 mm | 220 x 350 mm | 290 x 400 mm | 390 x 500 mm |
| Belt Size (W x L) | 160 x 280 mm | 230 x 350 mm | 230 x 450 mm | 300 x 500 mm | 400 x 650 mm |
| Power Supply | 230 V / 50 Hz | 230 V / 50 Hz | 230 V / 50 Hz | 230 V / 50 Hz | 230 V / 50 Hz |
1) Accuracy depends on weighing speed, weight and product type.
2) The belt speed can optionally be supplemented with continuous regulation.
